Quick Details

  • CAS No.: 67763-03-05
  • Other Names: Silical
  • MF: mSiO2 nH2O
  • EINECS No.: 231-545-4
  • Place of Origin: Shanghai, China (Mainland)
  • Classification: Other Adhesives
  • Main Raw Material: Silicone
  • Usage: Construction, Fiber & Garment, Footwear & Leather, Packing, Transportation, Woodworking, electronic,Metal,Glass,autobody,auto,automobile,automotive,car glass,
  • Brand Name: PUNADE
  • Model Number: SI1916T
  • Color: white.black,gray, transparent
  • Propetry: waterproof, weatherproof, age resistant
  • other Material: Silicone, Acrylic, Polyurethane, Epoxy
  • HS Code: 3506100090
  • Delivery time: fastest delivery(5~7days) and good quality
  • Samples: Free Samples
  • Shipping: By Express(Fedex, UPS ,DHL,TNT), or by sea
  • Elongation at break (%): 200
  • Share strength (MPa): ≥0.6
  • Hardness: 25 ± 5 Shore A

Packaging & Delivery

Packaging Details: 310ml cartridge, 25pcs/carton
310ml cartridge, 20pcs/carton CTN size:230*140*14.6mm ,GW.:10kg NW.:8.38Kg
Delivery Detail: Sample order:2-3 days; MOQ order:7-10 days

Mobile/Whatsapp/viber :0086 183 2120 8486 or add me on Skype:sallymzhang , let's talk more!!!

Core Advantage

Product Display

LED Suppliers SI1916 Neutral Silicone Sealant



RTV SI1916is one component semi-flowing sealant room temperature curing neutral

pouring silicone sealant. It has excellent bonding & sealing property to most of materials,

and for protecting the harsh condition electron component in the stable state.



SI1916T SI1916T-1 is a high-strength version, superior mechanical properties, better adhesion.

RTSI1916T, SI1916T-1 silicone adhesive sealant cured elastomer has the following characteristics:

Usage:

1. Used for Home appliances, industrial components etc bonding & seal.

2. Used for photovoltaic module ( PV)sealing.

3. Used for LED lamps.

4. Used for wall switch, PCB board and electronic components fixing

Features

1.Excellent chemical resistant

2.The silicone rubber has good elastic , good scrub resistant, and excellent adhesion.

3. No corrosion to most kinds of metal.

4. Excellent resistance to high—low alternative environment, (-60-260 )

  aging resistance and electrical insulation performance.

5. Excellent resistant to moisture, seismic, corona and electricity leakage performance.

6. Outdoor aging resistance, service life of up to 20--30 years.



Data Table



Testing standard

Testing standard

Unit

SI1916T

SI1916T-1

SI1916T-1-1

Properties before curing

Appearance



---

          Transparent

Viscosity(mPas) ()(mPa.s)*(mPa.s)*

GB/T 10247-2008

25℃,Pa·s

Paste

semi-flowing

20,000

Density(g/cm3)(g/cm3)(g/cm3)

GB/T 15223-1994

25,g/cm3

1.02±0.02

Touch dry time (Mins)

GB/T13477-2002

25℃,55%RH,min

10-15

Properties after curing

RTV curing

RTV

Hardness

GB/T 531-2008

Shore A

20

22

22

Thermal conductivity

GB/T 10297-1998

W/m.K

0.247

0.250

0.247

Elongation at break

GB/T 528-1998

%

250

250

200

Tensile strength

GB/T 528-2009

Mpa

1.5

2.0

1.5

Shear strength

GB/T 7124-2008

Mpa, Fe/Fe

1.2

2.3

1.6

Dielectric strength

GB/T 1695-2005

kV/mm(25℃)

20

20

20

Loss terms

GB/T 1693-2007

(1MHz) (25℃)

0.09

0.09

0.09

Dielectric constant

GB/T 1693-2007

(1MHz) (25℃)

2.9

2.9

2.9

Volume resistant

GB/T 1692-92

(DC500V) Ω· cm

2.00E +15







Operation

1. Cleaning: cleaning the surfaces that to be glued and coated, removing the rust, dust, greasy dirt and

other foreign matter and substance.

2. Gluing: cutting nozzle to the required angle, extruding the liquid cement to the cleaned surface and making

 it well-distributed, then folding and fixing the glued surfaces.

3. Curing: placing the glued or sealed components in the air to make them cured naturally.

Attention:

 1. Tightening and sealing the leftover sealant after the operation.        2. Removing the cured cement at the sealing part that might happen during the   preservation, it could be normally

used again.

Package & Storage

Product Model

SI 1916

Material

Silicon adhesive

Packaging

 310ml per tube, 25pcs with one CTN

shelf Life

12 months

Storage

1. Kept sealed in cool and dry place,the shelf life is 12 months when

stored below 25°C.

Shipping

Shipped and stored as normal chemicals

Production Process

Patent Certificate

Cooperation Brand

Packing And Shipping

Service Process

FAQ

1.Q:Delivery time ?



A: Normally,delivery time of sample order is 7 to 10 days,
standard order is 15-20 days.


2.Q:How to get samples ?



A: Normally,Sepna offer our customer 1-2pcs or 50-100g free samples for quality testing.


3.Q:How to be Sepna’s distributor ?



A: As the growing of Sepna’s global business,we need to find more and more distributors and agents
worldwide.Sepna will provide the best solution and service for our partners.
For more information,pls contact our salesperson or call us:+86-400-882-1323


4.Q:Any OEM service ?


A: Yes. Sepna can offer the customer OEM label service,and will give the protection of the your right in your market.


5.Q:Do you have MOQ ?


A:Yes.Normally,MOQ is 2000pcs or 1000kgs.
